ENV-03-3

Low Humidity Test Chamber

Simulate exceptionally dry environments down to 5% RH and -25 degC dew point using desiccant dehumidification.

5 degC to 50 degC 5% to 30% RH Dew point -25 degC

Overview

Purpose & Application

The ENV-03-3 low humidity chamber simulates extremely dry conditions from 5% to 30% relative humidity in the 5-50 degC range. Lower dew point reaches -25 degC. Desiccant-based dehumidification combined with controlled water evaporation gives stable low-RH set points for storage simulation, electronics conditioning and material studies.

Standard Models

Available Sizes

Model	Workspace (H x W x D)	Static Load	Thermal Load	Shelves
ENV-03-3-125 Liters	50 x 50 x 50 cm	10 Kg	20 W	1
ENV-03-3-450 Liters	75 x 75 x 80 cm	25 Kg	50 W	2
ENV-03-3-1000 Liters	100 x 100 x 100 cm	50 Kg	100 W	2
ENV-03-3-CB	Custom Built	Specify	Specify	Specify

We have delivered Hot Cold & Humidity Chambers up to 10 x 4.5 x 3.5 metres.

Technical Specifications

Key Specifications

Temperature Range

5 degC to 50 degC

Relative Humidity

5% to 30% RH

Control Accuracy

+/-0.5 degC and +/-2% RH

Dehumidification

Desiccant technology

Sensors

Pt-100 RTD + capacitive RH sensor

Construction

SS 304 18-gauge interior, CRCA exterior, PU paint

Power Supply

415 V, 3-phase or 230 V, 1-phase, 50 Hz

Lower Dew Point

-25 degC

Standard Features

Built-in Capabilities

Desiccant dehumidification down to -25 degC dew point
Controlled water evaporation humidification
Sealed compressor cooling
Multilayer observation window with illumination
Adjustable shelves throughout workspace
Standard port holes 50 / 100 / 150 mm
Caster wheels on models up to 1000 litres
Optional NABL calibration and data logger

Safety Systems

Protection & Reliability

Independent over- and under-temperature protection
High-discharge / low-suction pressure correction
Compressor trip on abnormal pressure
Over-current relays (OLR) and MCBs as required
Audio-visual alarm for critical functions
